Industrial Control Cabinet Monitoring & Dashboard
A professional industrial cabinet monitoring and control platform based on Raspberry Pi and RS485 Modbus,
designed for real-time monitoring, local control, and remote dashboard visualization.
The system integrates industrial-grade sensors, intelligent I/O modules, and a robust communication backbone
to provide accurate environmental monitoring, power status tracking, and equipment health diagnostics.
It supports continuous data polling, alarm triggering, and automated responses, ensuring reliable operation of
control cabinets, network racks, and field enclosures in harsh industrial environments.
Key Advantages
- Industrial-grade RS485 : Wired communication immune to EMI and signal drop
- Real-time Polling : Millisecond-level response for door, temperature, and power
- Precision Temperature Control : ±0.2°C accuracy, high-temperature tolerant sensors
- Full Power Analytics : Voltage, Current, Power Factor, and Energy (kWh)
- Edge Computing : Operates even without internet connection
- Tamper Detection : Door & intrusion alert with Line and Google Map
Map View with color status
Live voltage, current, and temperature gauges
Historical energy and temperature charts
